12V 100Ah Sealed Lead Acid Battery
Features
1. Small Internal Resistance
2. More Better Quality, More Better Consistency
3. Good Discharge, Long Life
4. Low temperature resistant
5. Stringing Walls Technology Will Transport Safer.
Application
Deep cycle maintenance free gel battery.Our products can be used in UPS,solar street light,solar power systems,wind system,alarm system and telecommunications etc.
Our AGM battery is also designed to withstand a wide range of environmental conditions. The high-quality construction and durable materials ensure reliable performance in both extreme temperatures and harsh operating environments. Whether you're powering a remote cabin in the mountains or a marine vessel on the open sea, our VRLA AGM battery is up to the task.
Parameters
Cell Per Unit | 6 |
Voltage Per Unit | 12V |
Capacity | 100AH@10hr-rate to 1.80V per cell @25°c |
Weight | 31KG |
Max. Discharge Current | 1000 A (5 sec) |
Internal Resistance | 3.5 M Omega |
Operating Temperature Range | Discharge: -40°c~50°c |
Charge: 0°c~50°c | |
Storage: -40°c~60°c | |
Normal Operating | 25°c±5°c |
Float charging | 13.6 to 14.8 VDC/unit Average at 25°c |
Recommended Maximum Charging Current | 10 A |
Equalization | 14.6 to 14.8 VDC/unit Average at 25°c |
Self Discharge | Batteries can be stored for more than 6 months at 25°c. Self-discharge ratio less than 3% per month at 25°c. Please charge batteries before using. |
Terminal | Terminal F5/F11 |
Container Material | A.B.S. UL94-HB, UL94-V0 Optional |
Dimensions
Structures
Installation and Use
Factory Video and Company Profile
FAQ
1. Do you accept customization?
Yes, customization is accepted.
(1) We can customize the color of the battery case for you. We have produced red- black,yellow-black,white-green and orange-green shells for customers, usually in 2 colors.
(2) You can also customize the logo for you.
(3) The capacity can also be customized for you, normally within 24ah-300ah.
2. Do you have a minimum order quantity?
Normally yes, if you have a freight forwarder in China to handle the transportation for you. One battery can also be sold to you, but the shipping fee will normally be more expensive.
3. How to maintain and use gel batteries?
(1). Ensure the normal charging of the gel battery.
When the gel battery is left unused for a long time, because the battery itself has self-discharge, we need to charge the battery in time.
(2). Choose a suitable charger.
If you use a charger, you need to use a charger with matching voltage and current. If it is used in an off-grid system, then a controller with voltage and current adaptation is required.
(3). Depth of discharge of gel battery.
Discharge under suitable DOD, long-term deep charge and deep discharge will affect the life of the battery. The DOD of gel batteries is generally recommended to be 70%.
4. TORCHN battery cycle life?
“The customer asked: What is the cycle life of your battery?I said: DOD 100% 400 times!The customer said: why so few, so and so battery 600 times?I ask: ls it 100% DOD?Customers say: What is 100%% DOD?”
The above conversations are often asked, First explain what is DOD100%.DOD is the depth of discharge, the latter? % Represents how much the rated capacity is used. For example: when the battery of a normal mobile phone reaches 80% DOD, the power will be displayed at 20%, the color of the battery logo will change or it will remind you to enter the power saving mode.The number of cycles is to use it once and count it as one cycle.
I will use my mobile phone as an example:
Xiao Ming is used to charging the phone every time the battery is 0, DOD100%.
Xiao Wang used to charge the mobile phone every time when 50% of the power was left,and the DOD was 50% lf two people use a mobile phone to make a 1,000-minute call, Xiao ming charges Xiao wang twice from one charge.DOD100% 1 time = DOD 50% 2 times.So the smaller the percentage behind the DOD, the more times it will be.You can see from the above example, Generally, lead-acid batteries are about 400 times too high and not much higher. We have to remember that the life of a battery is its capacity multiplied by its DOD 100% cycles 400 times. For example, 80Ah battery 80AH * 400 = 32000Ah, as long as the total discharge capacity of the 80Ah battery reaches 32000Ah.it is almost dead.DOD 100% 400 times has been considered the ideal state of lead-acid batteries, battery life will be affected a lot, many on the market say that lead-carbon batteries can reach 100% of DOD 100% or so. At present, it is still not fully mature in the experimental stage and entered the market , There are many factors affecting the number of battery cycles, the addition of grid alloys, lead paste auxiliary materials, improvement of assembly, improvement of exhaust valves, etc.
